Power Relay SPDT 12VDC
Web N°: 25-1758
$7.95
Power Relay SPDT 12VDC
Web N°: 25-1758
$7.95
Description
Series RT1, SCHRACK
Packaging Tube
Relay Type General Purpose
Coil Type Non Latching
Coil Current 33.3mA
Coil Voltage 12VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 16A
Switching Voltage 400VAC - Max
Turn On Voltage (Max) 8.4 VDC
Turn Off Voltage (Min) 1.2 VDC
Operate Time 8ms
Release Time 6ms
Features Insulation - Class F, Sealed - Flux Protection
Mounting Type Through Hole
Termination Style PC Pin
Contact Material Silver Nickel (AgNi)
Coil Power 400 mW
Coil Resistance 360 Ohms
Operating Temperature -40°C ~ 85°C
