5V 2A Relay (Compatible Arduino)
Web N°: 25-2166
$5.95
5V 2A Relay (Compatible Arduino)
Web N°: 25-2166
$5.95
Description
Relay Type General Purpose
Coil Type Latching, Single Coil
Coil Current 20.0mA
Coil Voltage 5VDC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 2A
Switching Voltage 250VAC, 220VDC - Max
Turn On Voltage (Max) 3.75 VDC
Turn Off Voltage (Min) -
Operate Time 2ms
Release Time 1ms
Features -
Mounting Type Through Hole
Termination Style PC Pin
Operating Temperature -40°C ~ 85°C
Contact Material Silver Alloy, Gold Alloy
Coil Power 100 mW
Coil Resistance 250 Ohms
