Mfr
|
Nichicon
|
|
Series
|
UPS
|
|
Package
|
Bulk
|
|
Capacitance
|
1500 µF
|
|
Tolerance
|
±20%
|
|
Voltage - Rated
|
16 V
|
|
Lifetime @ Temp.
|
3000 Hrs @ 105°C
|
|
Operating Temperature
|
-55°C ~ 105°C
|
|
Polarization
|
Polar
|
|
Applications
|
General Purpose
|
|
Ripple Current @ Low Frequency
|
1.088 A @ 120 Hz
|
|
Ripple Current @ High Frequency
|
1.25 A @ 100 kHz
|
|
Impedance
|
75 mOhms
|
|
Lead Spacing
|
0.197" (5.00mm)
|
|
Size / Dimension
|
0.492" Dia (12.50mm)
|
|
Height - Seated (Max)
|
0.866" (22.00mm)
|
|
Mounting Type
|
Through Hole
|
|
Package / Case
|
Radial, Can
|
