Insulation Displacement D-Subminiature 9 Pin Male Connector
Web N°: 26-0647
$1.95
Insulation Displacement D-Subminiature 9 Pin Male Connector
Web N°: 26-0647
$1.95
Description
- No exposed metal
- .050” offset contact spacing for standard flat “ribbon cable”
- Accepts 28 ga. solid, 30 ga. stranded
- Easily removable cable strain relief
- Shell: Thermoplastic
- Insulator Resistance: 1000m ohm min. at DC 500V
- Current Rating: 5 Amp
- Dielectric Strength: 1000V for 1 minute
- Operating Temperature: -55ºC - +105ºC
- Pin Contact: Phosphor Bronze Gold Plated over Nickel
- Insulator: PBT & 30% Glass Fiber (UL 94V-0)
