Green LED Lamp SPDT Round Paddle Lever Toggle Switch On/On
Web N°: 25-0581
$6.95
Green LED Lamp SPDT Round Paddle Lever Toggle Switch On/On
Web N°: 25-0581
$6.95
Details and Specifications
Current Rating: 6A 250VAC, 10A 125VAC.
Initial Contact Resistance:
Insulation Resistance: >100Meg Ohms.
Dielectric Strength (Open Contacts): >1500V for 1 minute.
Contact Material: Silver Plated Brass.
Terminal Material: Copper Alloy.
Body Material: Nylon (UL 94V-2).
Actuator & Bezel: Nylon (UL 94V-2).
Terminal Type: Solder Connection.
Mounting Hardware: M18 P1.0.
Lamp Voltage: LED 2V* @20ma (*resistor needed for other voltages).
LED indicator on top of lever.
